Distillation Column Manufacturer

Product Description:
The distillation column is suitable for the distillation of other solvents such as methanol. According to the needs of users, about 30% of dilute alcohol can be distilled to 90%~95% alcohol. The higher the requirement for the alcohol content of the finished product, the higher the reflux ratio can be increased, but the corresponding output will be reduced. The distillation tower uses efficient metal stainless steel packing. The department in contact with the solvent is made of stainless steel.

Application industries: pharmaceuticals, chemicals, food, biology

Operation mode: continuous distillation tower and intermittent distillation tower. The heating methods of the distillation tower include external circulation and internal circulation, with a recovery concentration of 90% -95% and residual liquid discharge of ≤ 0.19, which meets environmental protection requirements

Control method: Adopting condensation self flow reflux method, easy to operate, and can also achieve PIC automatic control

Items	JH-200	JH-300	JH-400	JH-500	JH-600	JH-800
Tower Volume (L)	640	1220	1450	2300	2500	3200
High Position Height (mm)	6000	7000	7000	7000	7500	7500
High Tank Volume (L)	300	400	650	800	1000	1500
Condensation Area (m²)	5	9	11	18	25	45
Cooling Area (m²)	1	1.5	2.2	4	6	8
Heat Exchange Area (m²)	3	6	6.5	10	15	26
Recovery Capacity (kg/h)	45-50	90-100	150-160	280-300	420-440	600-620
